Steel Gas Boilers of CLEVER L Series 100-200kW

Lemax high powerful steel floor gas boilers of the CLEVER L series are THE FIRST powerful heating water boilers with an atmospheric burner of a wide range of power modulation (50/60 / 70kW -150 / 180 / 200kW) of Russian origin. Floor-mounting equipment was designed for use in heating systems operating with forced circulation, it demonstrates high efficiency with a minimum ratio of coolant to the area and mass of the heat exchanger.

Learn More

Description

Description

The model range is 100 kW, 150 kW, 180 kW, 200 kW.

Operating pressure up to 6 atm.

Smooth power modulation in a ratio of 1:3, which ensures minimal load on the components of the heating system and minimizes gas consumption.

Low power consumption.

The improved systems of safety against freezing, overheating of the heat exchanger, reverse draft in the chimney, excess pressure of the coolant in the heating circuit.

Efficient operation with a minimum ratio of the volume of water in the boiler to the weight and area of the heat exchanger.

Resistance to voltage drops (180 - 245 V) and gas pressure (6-25 Mbar).

Connectivity: tank for indirect heating, sensor outdoor temperature, the circulation pump of the boiler and tank for indirect heating, thermostat for regulating the temperature of the coolant depending on the condition of the premises, the system remote control and comprehensive monitoring of the components of the heating system in Rs485 Protocol, External Fan of Lemax series models Comfort-150 and Comfort-180 (for CLEVER L150 and CLEVER L180).

Serviceability of the boiler through the use of removable lining.

Back to the list

Parameter	Clever L100	Clever L150	Clever L180	Clever L200
Nominal heating capacity in heating mode of 80/60, kW	Nominal heating capacity in heating mode of 80/60, kW 100	Nominal heating capacity in heating mode of 80/60, kW 150	Nominal heating capacity in heating mode of 80/60, kW 180	Nominal heating capacity in heating mode of 80/60, kW 200
Minimum heat output in heating mode of 80/60, kW	Minimum heat output in heating mode of 80/60, kW 30	Minimum heat output in heating mode of 80/60, kW 50	Minimum heat output in heating mode of 80/60, kW 60	Minimum heat output in heating mode of 80/60, kW 70
Efficiency, up to%	Efficiency, up to% 92	Efficiency, up to% 92	Efficiency, up to% 92	Efficiency, up to% 92
Nominal consumption of natural gas, m3 / h	Nominal consumption of natural gas, m3 / h 11,6	Nominal consumption of natural gas, m3 / h 17,5	Nominal consumption of natural gas, m3 / h 20,5	Nominal consumption of natural gas, m3 / h 23,2
Nominal gas pressure, Pa	Nominal gas pressure, Pa 1700-2500	Nominal gas pressure, Pa 1700-2500	Nominal gas pressure, Pa 1700-2500	Nominal gas pressure, Pa 1700-2500
Maximum operating pressure of the coolant at the boiler inlet, not more than	Maximum operating pressure of the coolant at the boiler inlet, not more than 0,6	Maximum operating pressure of the coolant at the boiler inlet, not more than 0,6	Maximum operating pressure of the coolant at the boiler inlet, not more than 0,6	Maximum operating pressure of the coolant at the boiler inlet, not more than 0,6
Minimum operating pressure of the coolant, MPa	Minimum operating pressure of the coolant, MPa 0,15	Minimum operating pressure of the coolant, MPa 0,15	Minimum operating pressure of the coolant, MPa 0,15	Minimum operating pressure of the coolant, MPa 0,15
Nominal water flow through the heat exchanger, l / min	Nominal water flow through the heat exchanger, l / min -	Nominal water flow through the heat exchanger, l / min 110	Nominal water flow through the heat exchanger, l / min 130	Nominal water flow through the heat exchanger, l / min 145
Hydraulic resistance, MPa	Hydraulic resistance, MPa 0,025	Hydraulic resistance, MPa 0,032	Hydraulic resistance, MPa 0,032	Hydraulic resistance, MPa 0,032
Exhaust air coefficient in flue gases	Exhaust air coefficient in flue gases 1,5-1,8	Exhaust air coefficient in flue gases 1,5-1,8	Exhaust air coefficient in flue gases 1,5-1,8	Exhaust air coefficient in flue gases 1,5-1,8
Diameter of flue duct, mm	Diameter of flue duct, mm 200	Diameter of flue duct, mm 300	Diameter of flue duct, mm 350	Diameter of flue duct, mm 350
Flue gas temperature with minimum heat output, ° C	Flue gas temperature with minimum heat output, ° C 80	Flue gas temperature with minimum heat output, ° C 90	Flue gas temperature with minimum heat output, ° C 85	Flue gas temperature with minimum heat output, ° C 90
Flue gas temperature at maximum heating capacity, ° C	Flue gas temperature at maximum heating capacity, ° C 120	Flue gas temperature at maximum heating capacity, ° C 165	Flue gas temperature at maximum heating capacity, ° C 170	Flue gas temperature at maximum heating capacity, ° C 170
Discharge behind the boiler, Pa	Discharge behind the boiler, Pa 200	Discharge behind the boiler, Pa 200	Discharge behind the boiler, Pa 200	Discharge behind the boiler, Pa 200
Water volume in the heat exchanger, l	Water volume in the heat exchanger, l 14	Water volume in the heat exchanger, l 22	Water volume in the heat exchanger, l 22	Water volume in the heat exchanger, l 22
Heat exchanger area, m2	Heat exchanger area, m2 11	Heat exchanger area, m2 16,2	Heat exchanger area, m2 18,3	Heat exchanger area, m2 19,3
Volume of firebox, m3	Volume of firebox, m3 0,7	Volume of firebox, m3 0,12	Volume of firebox, m3 0,12	Volume of firebox, m3 0,12
Maximum outlet water temperature with regard to regulation properties, ° C	Maximum outlet water temperature with regard to regulation properties, ° C 100	Maximum outlet water temperature with regard to regulation properties, ° C 100	Maximum outlet water temperature with regard to regulation properties, ° C 100	Maximum outlet water temperature with regard to regulation properties, ° C 100
Range of operation of the temperature controller, ° C	Range of operation of the temperature controller, ° C 50-95	Range of operation of the temperature controller, ° C 50-95	Range of operation of the temperature controller, ° C 50-95	Range of operation of the temperature controller, ° C 50-95
Connecting dimensions on the water contour, inch	Connecting dimensions on the water contour, inch G-2"	Connecting dimensions on the water contour, inch G-2"	Connecting dimensions on the water contour, inch G-2"	Connecting dimensions on the water contour, inch G-2"
Gas connection dimensions, in.	Gas connection dimensions, in. G-1 1/4	Gas connection dimensions, in. G-1 1/4	Gas connection dimensions, in. G-1 1/4	Gas connection dimensions, in. G-1 1/4
Connecting dimensions of flue gas outlet, mm	Connecting dimensions of flue gas outlet, mm 200	Connecting dimensions of flue gas outlet, mm 300	Connecting dimensions of flue gas outlet, mm 350	Connecting dimensions of flue gas outlet, mm 350
Power supply network parameters, V / Hz	Power supply network parameters, V / Hz 230/250	Power supply network parameters, V / Hz 230/250	Power supply network parameters, V / Hz 230/250	Power supply network parameters, V / Hz 230/250
Electrical power consumption (without optional equipment), W	Electrical power consumption (without optional equipment), W 34	Electrical power consumption (without optional equipment), W 42	Electrical power consumption (without optional equipment), W 51	Electrical power consumption (without optional equipment), W 51
Service life, years	Service life, years 10	Service life, years 10	Service life, years 10	Service life, years 10
Mass not more than, kg	Mass not more than, kg 145/163	Mass not more than, kg 250/280	Mass not more than, kg 258/288	Mass not more than, kg 260/290
