Gas Heating Facility Series Premier

The cylindrical form of the heat exchanger allows the facility to operate in closed systems (from 17,4 kw)
Anticorrosive enameled coating of heat exchanger having an exposure temperature 950 °C, and treatment of the heat exchanger with an inhibitory composition protect it against aggressive factors: solutions of salts, mineral oils during storage and transportation
Maximum operating pressure is 3 bar (with 17,4 kw)

Learn More

Description

Description

The model range is from 11,6 to 35 kW.

Maximum efficiency due to an increase in the heat exchange area and the use of an innovative design of turbulators for maximum delay of exhaust gases.

Operating pressure: from 17,4 to 35 kW - up to 3 atm., 11,6 kW - up to 1 atm.

The presence of the safety systems against interruption of traction, soot formation, blowing out of the heating apparatus.

The temperature controller with a scale is placed on the front panel of the device for convenience.

Work together with the Lemax monitoring and control device for remote monitoring and control of gas boilers and heating system indicators, via a mobile application.

Possibility of connecting a room thermostat to adjust the temperature inside the room.

Working together with the Lemax External Fan of the Comfort SE series for forced exhaust gas discharge in the absence of a stationary chimney.

A smooth start system that provides acoustic comfort at the time of the device's start.

Possibility of connecting a vertical or horizontal chimney.

Convenience of cleaning the boiler without disconnecting from the chimney due to the use of removable lining covers and a weight stabilizer.

The model range is from 55 to 100 kW.

Maximum efficiency due to an increase in the heat exchange area and the use of an innovative design of turbulators for maximum delay of exhaust gases.

Operating pressure: 55 kW - up to 3 atm., from 80 to 100 - up to 2 atm.

The presence of the safety systems against interruption of traction, soot formation, blowing out of the heating apparatus.

The temperature controller with a scale is placed on the front panel of the device for convenience.

Work together with the Lemax monitoring and control device for remote monitoring and control of gas boilers and heating system indicators, via a mobile application.

Possibility of connecting a room thermostat to adjust the temperature inside the room.

Working together with the Lemax External Fan of the Comfort SE series models XL (only for Premier-55) for forced exhaust gas discharge in the absence of a stationary chimney.

A smooth start system that provides acoustic comfort at the time of the device's start.

Ease of maintenance of the device due to the use of an easily removable top panel.

Parameter	Premier 11,6	Premier 17,4	Premier 23,2	Premier 29	Premier 35	Premier 55	Premier 80	Premier 100
Nominal heat power, kW	Nominal heat power, kW 11,6	Nominal heat power, kW 17,4	Nominal heat power, kW 23,2	Nominal heat power, kW 29	Nominal heat power, kW 35	Nominal heat power, kW 55	Nominal heat power, kW 80	Nominal heat power, kW 100
Energy conversion efficiency, % not less than	Energy conversion efficiency, % not less than 90	Energy conversion efficiency, % not less than 90	Energy conversion efficiency, % not less than 90	Energy conversion efficiency, % not less than 90	Energy conversion efficiency, % not less than 90	Energy conversion efficiency, % not less than 90	Energy conversion efficiency, % not less than 90	Energy conversion efficiency, % not less than 90
Nominal gas pressure, Pa	Nominal gas pressure, Pa 1300	Nominal gas pressure, Pa 1300	Nominal gas pressure, Pa 1300	Nominal gas pressure, Pa 1300	Nominal gas pressure, Pa 1300	Nominal gas pressure, Pa 1300	Nominal gas pressure, Pa 1300	Nominal gas pressure, Pa 1300
Average gas flow, m3/hr	Average gas flow, m3/hr	Average gas flow, m3/hr	Average gas flow, m3/hr	Average gas flow, m3/hr	Average gas flow, m3/hr	Average gas flow, m3/hr	Average gas flow, m3/hr	Average gas flow, m3/hr
- maximum	-maximum 1,16	-maximum 1,74	-maximum 2,32	-maximum 2,9	-maximum 3,5	-maximum 5,5	-maximum 8,0	-maximum 10,0
- avarage	- avarage 0,6	- avarage 0,9	- avarage 1,2	- avarage 1,5	- avarage 1,75	- avarage 2,75	- avarage 4,0	- avarage 5,0
Gas nominal pressure, mmWC	Gas nominal pressure, mmWC avarage 0,1	Gas nominal pressure, mmWC avarage 0,3	Gas nominal pressure, mmWC avarage 0,3	Gas nominal pressure, mmWC avarage 0,3	Gas nominal pressure, mmWC avarage 0,3	Gas nominal pressure, mmWC avarage 0,3	Gas nominal pressure, mmWC avarage 0,2	Gas nominal pressure, mmWC avarage 0,2
The range of discharge which ensures stable operation of the boiler, Pa	The range of discharge which ensures stable operation of the boiler, Pa 3-29	The range of discharge which ensures stable operation of the boiler, Pa 3-29	The range of discharge which ensures stable operation of the boiler, Pa 3-29	The range of discharge which ensures stable operation of the boiler, Pa 3-29	The range of discharge which ensures stable operation of the boiler, Pa 3-29	The range of discharge which ensures stable operation of the boiler, Pa 4-40	The range of discharge which ensures stable operation of the boiler, Pa 4-40	The range of discharge which ensures stable operation of the boiler, Pa 4-40
Flue-gas temperature °С, not less than	Flue-gas temperature °С, not less than 110	Flue-gas temperature °С, not less than 110	Flue-gas temperature °С, not less than 110	Flue-gas temperature °С, not less than 110	Flue-gas temperature °С, not less than 110	Flue-gas temperature °С, not less than 110	Flue-gas temperature °С, not less than 110	Flue-gas temperature °С, not less than 110
Fitting nipple diameter	Fitting nipple diameter 1½’’	Fitting nipple diameter 2’’	Fitting nipple diameter 2’’	Fitting nipple diameter 2’’	Fitting nipple diameter 2’’	Fitting nipple diameter 2’’	Fitting nipple diameter 2’’	Fitting nipple diameter 2’’
Gas nipple diameter	Gas nipple diameter ½’’	Gas nipple diameter ¾’’	Gas nipple diameter ¾’’	Gas nipple diameter ¾’’	Gas nipple diameter ¾’’	Gas nipple diameter ¾’’	Gas nipple diameter ¾’’	Gas nipple diameter ¾’’
Outer diameter of gas bleeding branch pipe, mm	Outer diameter of gas bleeding branch pipe, mm 120	Outer diameter of gas bleeding branch pipe, mm 130	Outer diameter of gas bleeding branch pipe, mm 140	Outer diameter of gas bleeding branch pipe, mm 140	Outer diameter of gas bleeding branch pipe, mm 140	Outer diameter of gas bleeding branch pipe, mm 200	Outer diameter of gas bleeding branch pipe, mm 200	Outer diameter of gas bleeding branch pipe, mm 200
Maximum heating medium temperature at the facility exit, °С	Maximum heating medium temperature at the facility exit, °С 90	Maximum heating medium temperature at the facility exit, °С 90	Maximum heating medium temperature at the facility exit, °С 90	Maximum heating medium temperature at the facility exit, °С 90	Maximum heating medium temperature at the facility exit, °С 90	Maximum heating medium temperature at the facility exit, °С 90	Maximum heating medium temperature at the facility exit, °С 90	Maximum heating medium temperature at the facility exit, °С 90
Dimensions, mm:	Dimensions, mm:	Dimensions, mm:	Dimensions, mm:	Dimensions, mm:	Dimensions, mm:	Dimensions, mm:	Dimensions, mm:	Dimensions, mm:
- height	- height 835	- height 865	- height 1065	- height 1065	- height 1065	- height 1102	- height 1280	- height 1280
- width	- width 324	- width 412	- width 465	- width 465	- width 465	- width 581	- width 754	- width 975
- depth	- depth 570	- depth 615	- depth 690	- depth 690	- depth 690	- depth 654	- depth 753	- depth 734
Weight, kg not more than	Weight, kg not more than 42/44	Weight, kg not more than 60/62	Weight, kg not more than 76/86	Weight, kg not more than 79/89	Weight, kg not more than 79/89	Weight, kg not more than 122/129	Weight, kg not more than 211/228	Weight, kg not more than 252/286
