Steel Gas Boilers of Patriot Series

Patriot series boilers with a closed combustion chamber operate with both open and sealed heating systems. The maximum operating pressure is up to 1.5 atm.

Learn More

Description

Description

The model range is from 6 to 20 kW.

Maximum efficiency due to an increase in the heat exchange area and the use of an innovative design of turbulators for maximum delay of exhaust gases.

Operating pressure - up to 1,5 atm.

Improved safety systems against overheating of the heat exchanger.

Coaxial smoke extraction system that does not require the organization of a stationary chimney(stainless steel configuration is possible).

Viewing window for monitoring the gorenje of the main andignition burners.

Ease of maintenance of the boiler due to the use of an easily removable top panel.

Name of parameters	Patriot‑6	Patriot‑7,5	Patriot‑10	Patriot‑12.5	Patriot‑16	Patriot‑20
Type of gas burner unit	Type of gas burner unit GGY-7,5p	Type of gas burner unit GGY-9p	Type of gas burner unit GGY-12P	Type of gas burner unit GGY-15p	Type of gas burner unit GGY-19P	Type of gas burner unit GGY-24P
Automatic safety controls	Automatic safety controls 630 EUROSIT	Automatic safety controls 630 EUROSIT	Automatic safety controls 630 EUROSIT	Automatic safety controls 630 EUROSIT	Automatic safety controls 630 EUROSIT	Automatic safety controls 630 EUROSIT
Rated heat output, kW	Rated heat output, kW 6	Rated heat output, kW 7,5	Rated heat output, kW 10	Rated heat output, kW 12,5	Rated heat output, kW 16	Rated heat output, kW 20
Efficiency factor, %	Efficiency factor, % 87	Efficiency factor, % 87	Efficiency factor, % 87	Efficiency factor, % 87	Efficiency factor, % 87	Efficiency factor, % 87
Approximate area of the heated space, m²	Approximate area of the heated space, m² 60	Approximate area of the heated space, m² 75	Approximate area of the heated space, m² 100	Approximate area of the heated space, m² 125	Approximate area of the heated space, m² 160	Approximate area of the heated space, m² 200
Volume of the heat carrier in the heat exchanger, l	Volume of the heat carrier in the heat exchanger, l 9,8	Volume of the heat carrier in the heat exchanger, l 9,8	Volume of the heat carrier in the heat exchanger, l 14,4	Volume of the heat carrier in the heat exchanger, l 14,4	Volume of the heat carrier in the heat exchanger, l 20,7	Volume of the heat carrier in the heat exchanger, l 20,7
Natural gas consumption. m³/h maximum medium	Natural gas consumption. m³/h maximum medium 0,75 0,38	Natural gas consumption. m³/h maximum medium 0,9 0,45	Natural gas consumption. m³/h maximum medium 1,2 0,6	Natural gas consumption. m³/h maximum medium 1,5 0,75	Natural gas consumption. m³/h maximum medium 1,9 0,95	Natural gas consumption. m³/h maximum medium 2,4 1,2
Process pressure of the heat carrier, MPa	Process pressure of the heat carrier, MPa 1,5	Process pressure of the heat carrier, MPa 1,5	Process pressure of the heat carrier, MPa 1,5	Process pressure of the heat carrier, MPa 1,5	Process pressure of the heat carrier, MPa 1,5	Process pressure of the heat carrier, MPa 1,5
Nominal pressure of natural gas. Pa	Nominal pressure of natural gas. Pa 1300	Nominal pressure of natural gas. Pa 1300	Nominal pressure of natural gas. Pa 1300	Nominal pressure of natural gas. Pa 1300	Nominal pressure of natural gas. Pa 1300	Nominal pressure of natural gas. Pa 1300
Temperature of combustion products. No less than. C	Temperature of combustion products. No less than. C 110	Temperature of combustion products. No less than. C 110	Temperature of combustion products. No less than. C 110	Temperature of combustion products. No less than. C 110	Temperature of combustion products. No less than. C 110	Temperature of combustion products. No less than. C 110
Maximum temperature of the heat carrier at the boiler outlet. С	Maximum temperature of the heat carrier at the boiler outlet. С 90	Maximum temperature of the heat carrier at the boiler outlet. С 90	Maximum temperature of the heat carrier at the boiler outlet. С 90	Maximum temperature of the heat carrier at the boiler outlet. С 90	Maximum temperature of the heat carrier at the boiler outlet. С 90	Maximum temperature of the heat carrier at the boiler outlet. С 90
Diameter of the coaxial flue, mm	Diameter of the coaxial flue, mm 250	Diameter of the coaxial flue, mm 250	Diameter of the coaxial flue, mm 250	Diameter of the coaxial flue, mm 250	Diameter of the coaxial flue, mm 310	Diameter of the coaxial flue, mm 310
Length of the coaxial flue, mm	Length of the coaxial flue, mm 330-800	Length of the coaxial flue, mm 330-800	Length of the coaxial flue, mm 330-800	Length of the coaxial flue, mm 330-800	Length of the coaxial flue, mm 330-800	Length of the coaxial flue, mm 330-800
Linkage dimensions of the branch pipes to the gas supply system, inch	Linkage dimensions of the branch pipes to the gas supply system, inch 1/2"	Linkage dimensions of the branch pipes to the gas supply system, inch 1/2"	Linkage dimensions of the branch pipes to the gas supply system, inch 1/2"	Linkage dimensions of the branch pipes to the gas supply system, inch 1/2"	Linkage dimensions of the branch pipes to the gas supply system, inch 1/2"	Linkage dimensions of the branch pipes to the gas supply system, inch 1/2"
Linkage dimensions of the branch pipes to the heating system, inch	Linkage dimensions of the branch pipes to the heating system, inch 1 1/2"	Linkage dimensions of the branch pipes to the heating system, inch 1 1/2"	Linkage dimensions of the branch pipes to the heating system, inch 1 1/2"	Linkage dimensions of the branch pipes to the heating system, inch 1 1/2"	Linkage dimensions of the branch pipes to the heating system, inch 2"	Linkage dimensions of the branch pipes to the heating system, inch 2"
Overall dimensions, mm	Overall dimensions, mm height 740 width 550 depth 310	Overall dimensions, mm height 740 width 550 depth 310	Overall dimensions, mm height 740 width 595 depth 360	Overall dimensions, mm height 740 width 595 depth 360	Overall dimensions, mm height 790 width 670 depth 400	Overall dimensions, mm height 790 width 670 depth 400
Mass, kg, no more than net gross	Mass, kg, no more than net gross 43 45	Mass, kg, no more than net gross 43 45	Mass, kg, no more than net gross 48 50	Mass, kg, no more than net gross 48 50	Mass, kg, no more than net gross 66 68	Mass, kg, no more than net gross 66 68
